Spider Platform Basket 18.90m
The Spider 18.90 articulated boom with fly jib is lightweight and easily transportable with an excellent weight/horizontal outreach ratio. This machine is agile and stable thanks to the variable track width for extra stability while travelling. This machine also allows the user to send through air/water and power cable from ground to cage.
Technical Specification
| Working height | 17.6m |
| Outreach | 9m (with 80kg) |
| Basket Capacity | 200kgs (Restricted) |
| Machine Weight | 2650kgs |
| Minimum Width | 790mm |
| Power | Diesel | Lithium Pack |
| Safe working load | 200kgs (Restricted) |
| Platform Height | 15.6m |
| Closed width | 790mm |
| Closed height Minimum | 1950mm |
| Non-marking tyres | Yes |
| Indoor use | Yes |
| Outdoor use | Yes |
| Weight | 2650kgs |
| Closed length (With Basket) | 5210mm |
| Closed Length (Without Basket) | 4560mm |
| Basket Rotation | Yes |
| Manufacturer | Platform Basket |
Industries
- Agriculture & Forestry
- Cleaning (Internal / External)
- Electrical (Internal / External)
- Energy Supply (Internal / External)
- Facilities Management (Internal External)
- Joinery & woodwork (Internal / External)
- Mechanical Engineering (Internal / External)
